Specifications of LG Split Air Conditioner 1.5 Ton BSNQ186K3A1 Dual Inverter

• Capacity: 1.5 Ton
• AC Functionality: Heating & Cooling
• AC Design: Wall Mount
• Inverter Type: DC
• Cooling Capacity: 18000 BTU
• Heating Capacity: 18000 BTU
• Gas: R 410a
• Voltage: 140 180 V
• Detachable Bottom Cover
• Tropical Dual Inverter Compressor
• works even 65 c
• Auto Cleaning
• Dual Protection Filter
• Silent Mode

Specifications of LG Split Air Conditioner 2.0 Ton I24CGH DUALCOOL Inverter

• Dual Inverter Compressor™
• TUV Rheinland
• Energy Saving
• Fast Cooling

CAPACITY

Cooling – Min ~ Rated ~ Max(kW) 1.26/6.45/7.18

Cooling – Min ~ Rated ~ Max(Btu/h) 3,500/22,000/24,500

Heating – Min ~ Rated ~ Max(kW) 1.26/6.45/7.32

Heating – Min ~ Rated ~ Max(Btu/h) 3,500/22,000/24,500

POWER INPUT

Cooling – Min ~ Rated ~ Max(W) 240/2,010/2,420

Heating – Min ~ Rated ~ Max(W) 240/1,890/2,500

RUNNING CURRENT

Cooling – Min ~ Rated ~ Max(A) 1.14/9.60/11.46

Heating – Min ~ Rated ~ Max(A) 1.14/9.10/11.84

EER

EER(W/W) 3.21EER((Btu/h)/W) 10.95

COP

COP(W/W) 3.41COP((Btu/h)/W) 11.64

POWER SUPPLY

Ø, V, Hz 1, 220 ~ 240, 50

AVAILABLE VOLTAGE RANGE

Available Voltage Range(V) 187 ~ 276

POWER FACTOR

Cooling/Heating(%) 95/95

MOISTURE REMOVAL

Moisture Removal(l/h) 2.00

INDOOR

Air Flow Rate – Cooling, Max/H/M/L(m³/min) 21/15/12/9

Air Flow Rate – Heating, Max/H/M/L(m³/min) 21/16/13/9.5

Sound Pressure Level – Cooling, H/M/L/SL(dB(A)) 56/48/43/38/32

Sound Pressure Level – Heating, Max/H/M/L(dB(A)) 57/48/43/38

Dimensions (W×H×D) – Net(mm) 998 × 345 × 210

Dimensions (W×H×D) – Shipping(mm) 1080×422×281

Weight – Net(kg) 12.1Weight – Shipping(kg) 14.5

Exterior Color Code Munsell 7.5BG 10/2 (RAL 9016)

OUTDOOR

Air Flow Rate – Max(㎥/min) 50.0

Fan Motor Speed – Cooling, Min ~ Max(rpm) 190 ~ 800

Fan Motor Speed – Heating, Min ~ Max(rpm)) 190 ~ 840

Sound Pressure Level – Cooling, Rated(dB(A)) 56

Sound Pressure Level – Heating, Rated(dB(A)) 58

Dimensions (W×H×D) – Net(mm) 870 × 655 × 320

Dimensions (W×H×D) – Shipping(mm) 1017 × 718.6 × 432

Weight – Net(kg) 42.7

Weight – Shipping(kg) 50.0Max.

Fuse Size(A) 20

Exterior Color Code Munsell 9.54Y 8.34/1.31 (RAL 9001)Operation Range – Cooling(℃ DB) 18 ~ 48

Operation Range – Heating(°C DB) -5 ~ 24Operation Range – Heating(℃ WB) -5 ~ 18

CIRCUIT BREAKER

Circuit Breaker(A) 20

POWER SUPPLY CABLE

Power Supply Cable(No. x mm2) 3 × 1.5

POWER SUPPLY TO UNIT

Power Supply to Unit Outdoor

POWER AND COMMUNICATION CABLE

Power and Communication Cable(No.×mm²) 4 × 0.75

PIPING

Size – Liquid(mm) Ø 6.35

Size – Gas(mm) Ø 15.88

Connections Method – Indoor/Outdoor Flared/Flared

DRAIN HOSE SIZE

O.D, I.D(mm) 21.5, 16.0

BETWEEN INDOOR & OUTDOOR

Piping Length – Min/Standard/Max(m) 3.6/5/20

Piping Length – No Charge(m) 5.0

Max. Elevation Difference(m) 10

Piping Connection Heat Insulation Both liquid and Gas Pipes

REFRIGERANT

Type R410APre Charge(g) 1400

Additional Charge(g/m) 20Control Capillary

Global Warning Potential 2087.5t-CO₂ eq 2.923

DEFROST METHOD

Defrost Method Reverse Cycle

TOOL CODE (CHASSIS)

Indoor/Outdoor SK/UE

COMPRESSOR

Type Twin Rotary

Model GAT156MAC

Motor Type BLDC

Oil Type/Maker POE (RB68A)/Sun Oil or Jx Nippon

Oil Charge(cc) 400

FAN(INDOOR)

Type Cross Flow FanMotor

Output(W) 58

FAN(OUTDOOR)

Type Propeller FanMotor

Type BLDC

Motor Output(W) 85.5

Motor Insulation Class E

Motor Enclosure/Ingress

Protection TEAO/IPX5

HEAT EXCHANGER

Evaporator – Material, Tube/Fin Cu/AlEvaporator – (ø x Row x Column x FPI x L) x Qty.(#1) (ø7 x 2 x 16 x 20 x 744) x 1

Evaporator – (ø x Row x Column x FPI x L) x Qty.(#2) (ø5 x 1 x 4 x 22 x 744) x 2Evaporator – Corrosion Protection PCM

Evaporator – Fin Type SlitCondenser – Material, Tube/Fin Cu/Al

Condenser – (ø x Row x Column x FPI x L) x Qty.(#1) (ø7 x 2 x 28 x 18 x 831.5) x 1Condenser – Corrosion Protection Gold

Condenser – Fin Type Louver
